Sold as single unit
Hand-crafted in the USA, Dapper Lighting has redefined aesthetics and functionality of classic car illumination. If you have been looking for state-of-the-art lighting technology, modern features, and timeless style, then the search stops here.
Besides being the slimmest 5.75-inch projector light ever created, you’ll find that beneath the exterior lies a powerhouse of lighting prowess. Designed with modern halogen bulbs, you will find an increase of brightness and longer lifespan versus the older sealed beam technology.
Our advanced projector technology ensures a brilliant and focused beam that illuminates the road ahead with unprecedented clarity. Navigate dark nights and the most challenging weather conditions with confidence.
Choose from a range of customizable options to create a headlight that resonates with your desired style. Whether you prefer a modern, futuristic look or a classic, timeless appeal, the 575 can be tailored to your vision.
Warrantied for 5 years and backed by customer service expertise from real car people, we can assure you your journey from selecting lights to driving them down the road will be an investment you can enjoy every step of the way.
Redefine your driving perspective, turn heads, and enjoy the ultimate blend of form and function. Enter a new driving experience with Dapper Lighting’s 575.
Plug and Play- Our included adapter plugs right into your factory headlight harness for easy installation
Performance– Over 2.5x the lumens of a standard sealed beam (with upgraded 30W LEDs)
Glass Lens– Glass lens to prevent UV fading and dulling
No Glare– Featuring a custom designed projector, the flat razor sharp light no glare output ensures you aren’t blinding oncoming traffic
Four High– The inline wiring harness automatically enables all four lights for high beams
Low Power / High Output– The optional LED Optical unit provides the balance between brightness, heat dispersion, and reliability
Modular– Replaceable components ensure a long lasting, serviceable, and upgradable headlamp
Low Beam Direct Replacement
for: 5006
High Beam Direct Replacement
for: 5001
High/Low Direct Replacement
for: PAR46, H5006, H5001
Halogen:
Color Temp (CCT): 3000K
Power Halogen (watts): 55W
Current (amps @ 12.8V): 4.3A
Cooling: None
13W LED:
Color Temp (CCT): 6000K
Power Halogen (watts): 13W
Current (amps @ 12.8V): 1A
Cooling: Passive Fin
30W LED:
Color Temp (CCT): 6000K
Power Halogen (watts): 30W
Current (amps @ 12.8V): 2.3A
Cooling: Active
Polarity: Polarity Specific
Operating Temperature: -40C to 85C (-40F to 185F)
Connector(s): H11/H4
Materials: Borosilicate Glass Lens, Polymide Nylon 66 Housing, Rubber Gasket
Product Dimensions (in): 14x11x7
Unit Weight (lb): 2.0
Shipped Weight (lb): 2.5
⚠️California Proposition 65 Warning: This product contains chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.
For more information: www.p65warnings.ca.gov
Specifications/Dimensions Sheet for Low Beam Chrome 13W LED 575:
